Coleman Presidential 2 Furnace: A Comprehensive Guide
This detailed guide offers essential information for owners, covering operation, maintenance, and troubleshooting of the Coleman Presidential 2 furnace for optimal heating.
Understanding Your Furnace
The Coleman Presidential 2 furnace is a forced-air heating system commonly found in manufactured homes and mobile homes. Familiarizing yourself with its core components is crucial for effective operation and maintenance; This furnace utilizes either a standing pilot light or electronic ignition to ignite the gas, initiating the heating process.
Key components include the burner assembly, blower motor, heat exchanger, control board, and various safety devices. The control board orchestrates the entire heating cycle, responding to thermostat signals and monitoring safety parameters. Understanding how these parts interact allows for more informed troubleshooting. Regularly consulting the Coleman Presidential 2 furnace manual provides detailed diagrams and operational explanations, ensuring safe and efficient performance throughout the heating season. Proper understanding extends the lifespan of your heating system.
Key Features of the Presidential 2 Model
The Coleman Presidential 2 furnace boasts several features designed for reliable and efficient heating. It typically offers multi-speed blower operation, allowing for customized airflow and comfort levels. Many models include a safety lockout system, automatically shutting down the furnace in case of detected issues like flame failure or overheating.
The unit’s compact design facilitates easy installation in various mobile home configurations. The Coleman Presidential 2 furnace manual details specific BTU input ratings and efficiency levels for each model. Furthermore, the furnace often incorporates a diagnostic indicator light to assist in identifying potential problems. These features combine to deliver consistent warmth and peace of mind, making it a popular choice for manufactured housing.
Safety Precautions Before Troubleshooting
Prioritize safety when addressing any issues with your Coleman Presidential 2 furnace. Always disconnect the power supply – both electrical and gas – before commencing any inspection or repair work. Gas leaks pose a significant hazard; if you smell gas, immediately evacuate and contact your gas company.
Never attempt repairs if you are uncomfortable or lack the necessary expertise. Refer to the Coleman Presidential 2 furnace manual for detailed safety guidelines and warnings. Wear appropriate safety gear, including gloves and eye protection. Be mindful of hot surfaces and sharp edges. Improper handling can lead to burns, electric shock, or gas poisoning. When in doubt, consult a qualified HVAC technician.
Troubleshooting Common Issues
This section details solutions for frequent problems with your Coleman Presidential 2 furnace, ensuring efficient heating and addressing potential malfunctions quickly.
Furnace Fails to Start
When your Coleman Presidential 2 furnace doesn’t ignite, several factors could be at play. Begin by checking the thermostat settings, ensuring it’s set to “Heat” and the desired temperature is higher than the room temperature. If using a model with a pilot light, carefully inspect it to confirm it’s lit; relight if necessary, following the manufacturer’s instructions.
A crucial step is verifying the power supply. Check the circuit breaker dedicated to the furnace and reset it if tripped. Also, confirm the furnace’s power switch is in the “On” position. Intermittent blower failure is common, suggesting a potential issue with the blower motor or control board. Remember to turn off power before any inspection!
Checking the Thermostat Settings
A surprisingly common reason for a furnace failing to start is simply incorrect thermostat settings. First, ensure the thermostat is switched to the “Heat” mode, not “Cool” or “Off”. Verify the set temperature is several degrees higher than the current room temperature; the furnace won’t activate if it believes the desired temperature has already been reached.
If your thermostat uses batteries, check and replace them if they’re low. A weak battery can cause inaccurate readings or prevent the thermostat from communicating with the furnace. To test the thermostat itself, carefully turn off the furnace’s power and then attempt to manually activate the heating cycle.
Inspecting the Pilot Light (if applicable)
If your Coleman Presidential 2 furnace utilizes a standing pilot light – older models often do – a visual inspection is crucial. Locate the pilot light access panel (refer to your furnace manual for its exact location). Carefully observe the pilot light flame; it should be a steady, blue flame. A yellow or flickering flame indicates potential issues with the gas supply or venting.
If the pilot light is out, follow the relighting instructions printed on the furnace itself. Never attempt to relight the pilot if you smell gas. If the pilot light repeatedly extinguishes, there may be a problem with the thermocouple, a safety device that shuts off the gas if the pilot isn’t lit.
Verifying Power Supply
Before diving into more complex troubleshooting, ensure your Coleman Presidential 2 furnace is receiving power. Begin by checking the circuit breaker dedicated to the furnace in your electrical panel. If tripped, reset it. If it trips again immediately, there’s likely a short circuit requiring professional attention.
Next, verify the furnace’s disconnect switch (usually located near the unit) is in the “on” position. Use a non-contact voltage tester to confirm voltage is present at the furnace’s wiring connections. Always turn off power at the breaker before working with electrical components. A lack of power is a common cause of furnace failure, so this simple check is essential.
Blower Motor Not Working
A non-functioning blower motor prevents warm air from circulating, leaving your home cold. Initial investigation should focus on the blower relay, a frequent point of failure in Coleman Presidential 2 furnaces. Locate this relay – often near the control board – and inspect it for signs of damage or burnout. Testing the relay with a multimeter can confirm its functionality.
If the relay tests good, directly testing the blower motor itself is the next step. Ensure power is disconnected before attempting this! A faulty control board can also prevent the motor from receiving power. Careful examination of the board for burnt components or loose connections is crucial.
Identifying the Blower Relay
The blower relay is a crucial component responsible for supplying power to the blower motor, initiating warm air circulation. In the Coleman Presidential 2 furnace, it’s typically a small, cube-shaped component located near the control board, often within the furnace’s control panel. It usually has several wires connected to it, facilitating power transfer.
Visually, look for a relay with markings indicating its function – though these can be faded. Referencing a wiring diagram specific to your model is highly recommended for accurate identification. The relay’s location can vary slightly depending on the specific Presidential 2 sub-model, so precise diagram consultation is key. A faulty relay will prevent the blower from starting.
Testing the Blower Motor Directly
If the blower relay seems functional, directly testing the blower motor is the next step. Caution: Disconnect power to the furnace before proceeding! Locate the blower motor and its wiring connections. Using a multimeter set to measure resistance, check the motor windings for continuity. An open circuit indicates a failed motor.
Carefully apply the correct voltage (typically 120V – verify with the furnace label!) directly to the motor terminals, observing proper polarity. If the motor doesn’t run, it’s likely defective and requires replacement. Ensure the motor spins freely before applying power. A seized motor also necessitates replacement. Always prioritize safety when working with electrical components.
Examining the Control Board
If the blower motor and relay check out, the control board becomes the prime suspect. Visually inspect the board for any signs of damage – burnt components, swollen capacitors, or cracked solder joints. Caution: Disconnect power before inspection! Use a multimeter to check for voltage at the blower motor connection on the control board when the thermostat calls for heat.
If voltage is present but the motor isn’t running, the board may be faulty. Carefully examine the board’s wiring connections, ensuring they are secure. A failing control board often exhibits erratic behavior or complete failure to activate components. Replacement may be necessary, and professional assistance is recommended for this complex repair.
Furnace Blows Cold Air
A furnace delivering cold air indicates a problem preventing effective heat exchange. Begin with the simplest check: the air filter. A clogged filter restricts airflow, reducing heating efficiency. Replace it with a clean one. Next, inspect the ductwork for leaks – these allow heated air to escape, diminishing warmth at the vents. Seal any discovered leaks with duct tape or mastic sealant.
If these steps don’t resolve the issue, verify the gas supply. Ensure the gas valve is open and that there are no obstructions in the gas line. A lack of gas will prevent the furnace from generating heat. If gas supply is confirmed, further diagnostics may be needed, potentially involving the burner assembly or heat exchanger.
Air Filter Inspection and Replacement
Regular air filter maintenance is crucial for your Coleman Presidential 2 furnace’s efficiency and longevity. A dirty filter restricts airflow, forcing the blower motor to work harder, potentially leading to overheating and failure. Inspect the filter monthly, and replace it at least every one to three months, depending on usage and air quality.
To locate the filter, consult your furnace manual – it’s typically found in a slot near the blower compartment. Remove the old filter, noting the airflow direction arrow printed on its frame. Install the new filter with the arrow pointing in the same direction. A clean filter ensures optimal airflow, improved heating, and reduced energy costs.
Checking for Ductwork Leaks
If your Coleman Presidential 2 furnace blows cold air, ductwork leaks are a common culprit. Leaks allow heated air to escape into unconditioned spaces, reducing heating efficiency and increasing energy bills. Inspect visible ductwork for obvious tears, disconnections, or loose seals.
Feel for air escaping around joints and seams when the furnace is running. Use duct tape (specifically designed for HVAC systems – not standard duct tape!) to seal small leaks. For larger issues or leaks in inaccessible areas, consider professional duct sealing. Addressing ductwork leaks significantly improves heating performance and comfort throughout your home.
Gas Supply Verification
If your Coleman Presidential 2 furnace isn’t heating properly, verifying the gas supply is crucial. First, ensure the main gas valve supplying your home is fully open. Then, check the gas shut-off valve specifically for the furnace – it should also be in the ‘on’ position.
Caution: If you smell gas, immediately shut off the gas supply and contact your local gas company or a qualified HVAC technician. Do not attempt to troubleshoot further. A professional can safely assess the gas pressure and connections to ensure adequate supply to the furnace, resolving potential heating issues.
Maintenance and Care
Regular upkeep, including filter changes and burner cleaning, extends the life of your Coleman Presidential 2 furnace and ensures efficient, reliable heating performance.
Regular Filter Changes
Maintaining a clean air filter is arguably the most crucial aspect of Coleman Presidential 2 furnace care. A dirty filter restricts airflow, forcing the blower motor to work harder, reducing efficiency, and potentially leading to overheating and premature failure.
Inspect your filter monthly, and replace it at least every one to three months, depending on usage and air quality. If you have pets or allergies, more frequent changes are recommended. The filter is typically located in a designated slot within the furnace’s return air duct.
Always turn off the furnace power before removing and replacing the filter. Use the correct filter size as specified in your Coleman Presidential 2 furnace manual to ensure proper fit and optimal performance. A clean filter contributes to better air quality and lower energy bills.
Cleaning the Burner Assembly
Regularly cleaning the burner assembly ensures efficient combustion and prevents potential safety hazards. Always disconnect the gas supply and electrical power before attempting any cleaning. Use a vacuum cleaner with a brush attachment to carefully remove dust, debris, and lint from the burner, pilot assembly (if applicable), and surrounding areas.
Inspect the burner for any signs of corrosion or damage. A soft brush can dislodge stubborn particles. Do not use water or cleaning solutions, as these can damage components.
Carefully reassemble the burner assembly, ensuring all parts are securely in place. Refer to your Coleman Presidential 2 furnace manual for specific diagrams and instructions. A clean burner promotes safe and efficient operation, maximizing heating performance.
Professional Inspection Schedule
While diligent homeowner maintenance is crucial, a professional inspection of your Coleman Presidential 2 furnace is vital for long-term reliability and safety. Schedule a comprehensive inspection annually, ideally before the heating season begins. A qualified HVAC technician will assess gas connections, combustion efficiency, and overall system performance.
They can identify potential issues – like carbon monoxide leaks or developing cracks in the heat exchanger – that may not be visible during routine checks. Professional cleaning of internal components ensures optimal airflow and efficiency.
Adhering to a regular inspection schedule extends the furnace’s lifespan and provides peace of mind, guaranteeing safe and efficient heating for years to come.
Wiring Diagrams and Schematics
Accessing accurate wiring diagrams and schematics is essential for safe and effective troubleshooting and repair of your Coleman Presidential 2 furnace system.
Locating Wiring Diagrams Online
Finding the correct wiring diagram for your Coleman Presidential 2 furnace often begins with a thorough online search. Manufacturer websites, like Coleman’s official support portal, are excellent starting points, though specific older models may require more digging. Numerous online forums dedicated to mobile home repair and HVAC systems frequently host user-submitted diagrams and discussions. Websites specializing in appliance repair manuals, often subscription-based, can also provide detailed schematics.
Be sure to have your furnace’s model number (e.g., 3118B750) readily available, as this is crucial for identifying the correct diagram. Carefully compare the diagram to your furnace’s wiring to confirm accuracy before attempting any repairs. Remember that discrepancies can occur, and consulting a qualified HVAC technician is always recommended if you are unsure.
Understanding Schematic Symbols
Successfully interpreting a Coleman Presidential 2 furnace schematic requires familiarity with standard electrical symbols. A straight line typically represents a wire, while a circle denotes a component like a capacitor or relay. Resistors are often depicted as zig-zag lines, and transformers as coiled symbols. Understanding these basic representations is crucial for tracing circuits and diagnosing issues.
Pay close attention to symbols indicating voltage and grounding. A triangle often signifies a ground connection, while voltage is indicated numerically. Familiarize yourself with symbols specific to furnace components, such as gas valves and igniters. Incorrectly interpreting these symbols can lead to misdiagnosis and potentially dangerous repairs; professional guidance is advised if unsure.
Identifying the Time Delay Relay (and potential miswiring)
The time delay relay, if present in your Coleman Presidential 2, controls the sequencing of operations, particularly the blower motor’s start-up after ignition. However, some diagrams omit this component, raising concerns about potential miswiring during previous repairs. Look for a small, cube-shaped relay with multiple wire connections.
Miswiring can cause the blower to operate incorrectly or not at all. Carefully compare the actual wiring to a verified schematic. A common error involves swapping wires, disrupting the timed sequence. If discrepancies exist, or if you suspect incorrect connections, consult a qualified technician to avoid damaging the furnace or creating a safety hazard.
